Corrugated Sidewall Conveyor Belt
Unlock Vertical Conveying – Maximize Your Space, Move Materials with Confidence
Facing Challenges with Steep Inclines or Limited Space?
Transporting bulk materials on sharp slopes or within confined spaces often leads to material spillage, reduced efficiency, and higher operating costs. Our Corrugated Sidewall Conveyor Belts are designed to conquer these problems, enabling you to move materials vertically or at steep angles with unmatched reliability and safety.
Why Choose Our Corrugated Sidewall Conveyor Belts?
1. True Vertical & Steep-Angle Transport
Engineered to carry materials at angles up to 90°, our belts let you make full use of vertical space—no more costly transfer points or complex conveyor layouts.
2. Robust Sidewalls and Cleats
High-strength, flexible sidewalls and securely bonded cleats form sealed compartments, preventing spillage and ensuring that even fine powders or large lumps are transported smoothly.
3. Customized for Your Operation
We offer a wide range of belt widths, sidewall heights, cleat types, and rubber compounds. Our engineering team works with you to design a solution tailored to your unique process and material.
4. Minimized Maintenance, Maximum Uptime
Our sidewall belts are built for demanding environments. Advanced bonding techniques reduce the risk of delamination, while reinforced edges and wear-resistant rubber extend service life—keeping your plant running with less downtime.
5. Industry-Proven Versatility
From mining and power generation to cement, agriculture, and port facilities, our corrugated sidewall belts are trusted worldwide for vertical and steep-angle conveying of everything from ore and coal to grains and fertilizers.
Typical Applications
Mining and mineral processing
Power plants and steelworks
Cement, aggregate, and construction materials
Chemical and fertilizer plants
Grain, feed, and bulk agriculture handling
Port terminals and ship loading systems
| Item | Range / Specification |
|---|---|
| Belt Width | 300 mm – 2600 mm |
| Belt Thickness | 6 mm – 25 mm |
| Number of Plies | 2 – 6 plies (higher available) |
| Tensile Strength | EP100, EP125, EP150, EP200, EP300, EP350, EP400, EP500+ |
| Cover Thickness | Top: 1.5–8 mm / Bottom: 0.5–4 mm |
| Elongation at Full Load | ≤ 1.5% |
| Operating Temperature | -60°C to 60°C (standard), up to 600°C continuous, 800°C instant (heat-resistant) |
FAQ
Q: Can your sidewall belts handle both fine and large materials?
A: Absolutely. Our belts are designed for reliable transport of fine powders, granules, and large bulk materials, even on vertical runs.
Q: Are custom sizes available for existing systems?
A: Yes. We tailor sidewall, cleat height, and belt width to match your conveyor layout and material requirements.
Q: How long is the typical delivery time?
A: Standard sizes are often available from stock. Custom solutions are delivered fast—contact our team for details based on your location and order size.
Ready to Upgrade Your Conveyor System?
Stop losing materials and energy to old designs.
Get in touch for a free consultation and competitive quote on your next corrugated sidewall belt project.
